Universal HDD UNI 250x400 Directional Drill
The UNI 250x400 Directional Drill by Universal HDD is a powerhouse designed for the most demanding long-range horizontal directional drilling (HDD) projects. With its exceptional thrust and pullback capabilities, high torque output, and operator-centric features, the UNI 250x400 ensures efficiency and precision in challenging drilling environments.
Specifications
| Drill Pipe Length | 20.0 ft |
| Gross Horsepower | 400.0 hp |
| Rated RPM | 2200.0 rpm |
| Horsepower | 400.0 hp |
| Emissions Tier | Tier IV |
| Fuel Tank Capacity | 142.0 gal |
| Hydraulic Tank Capacity | 154.0 gal |
| Maximum Thrust | 250000.0 lbs |
| Spindle Torque | 40000.0 ft-lb |
| Maximum Pullback | 250000.0 lbs |
| Maximum Spindle Speed | 100.0 rpm |
Current Promotions
Current promotions can save you money. We offer promotions that may include Low finance rates, cash back, bonus attachments and more. Check out our current promotional offers to see what may apply to your next equipment purchase.
Specifications and images may vary in accuracy.
Data Powered By EquipmentWatch
