DEVELON DX17Z-7 Mini Excavator
The DEVELON DX17Z-7 mini excavator is engineered to conquer your most confined job sites. Featuring an undercarriage width that narrows to just 39 inches, this machine easily passes through tight property lines and access points. Once in position, the tracks can expand to 51 inches to create a highly stable digging platform.
It boasts an impressive 88-inch dig depth and is powered by dual 4.5 gpm main pumps, providing a combined 9.0 gpm of hydraulic flow for smooth, responsive attachment performance. Combined with a true Zero Tail Swing design, the DX17Z-7 is the perfect solution for residential landscaping and close-quarters utility work.
Specifications
| Operator Protection | ROPS/TOPS |
| Tail Swing Type | Zero Tail Swing |
| Operating Weight | 4210.0 lb |
| Overall Width | 39.0 in |
| Overall Width (extended) | 51.0 in |
| Overall Height | 91.0 in |
| Overall Length | 139.0 in |
| Horsepower | 16.5 hp |
| Engine Manufacturer | Kubota |
| Engine Model | D902 |
| Emissions Tier | Tier 4 Final |
| Fuel Tank Capacity | 5.2 gal |
| Maximum Digging Depth | 88.0 in |
| Maximum Reach at Ground Level | 150.0 in |
| Maximum Dumping Height | 105.0 in |
| Bucket Breakout Force | 3668.0 lbf |
| Stick Digging Force - Standard | 2057.0 lbf |
| Blade Size (H x W) | 9 x 39 (51 extended) in |
| Arm Configuration | Standard |
| Auxiliary Circuit Flow | 9.0 gal/min |
| Track Shoe Type | Rubber |
| Ground Pressure | 4.4 psi |
