Linde R20 Electric Narrow Aisle Reach Truck
The Linde R20 reach truck is designed for maximum strength and durability without sacrificing stability or efficiency. It's an ideal assistant for large warehouses and manufacturing settings, with a focus on safety, reliability, and comfort.
With a rated load capacity up to 4,400 lbs, it handles heavy pallets confidently while maintaining precise control at height. You can expect mast lift heights of 352-inches to match your racking profile, and the compact chassis and 180° steering deliver nimble handling in tight aisles. A tight turning radius of 70-inches on the R20 helps operators work efficiently in narrow spaces without compromising stability.
Current Promotions
Current promotions can save you money. We offer promotions that may include Low finance rates, cash back, bonus attachments and more. Check out our current promotional offers to see what may apply to your next equipment purchase.
Linde R20 Specifications
| Lift Capacity | 4400.0 lbs |
| Max Lift Height | 171.5 - 451 in |
| Free Lift Height | 39.4 - 149.6 in |
| Lowered Overall Height | 83.9 - 194.1 in |
| Mast Type | Triplex Clearview |
| Operating Weight | 9656.0 lbs |
| Baseleg Outer Width | 50 in |
| Overall Length (to Fork Face) | 55.0 in |
| Overhead Guard Height | 83.1 in |
| Turning Radius | 70.0 in |
| Minimum Aisle Width | 112.8 in |
| Travel Speed (Unloaded) | 8.7 mph |
| Lift Speed (Loaded) | 91 fpm |
| Steering Type | Rheological Electric Steering |
| Tire Type | Polyurethane |
| Power Mode | Battery (Lead-Acid / Li-ION) |
| Voltage | 48 V |
Specifications and images may vary in accuracy.
