Doppstadt INVENTHOR Type 6.2 Slow-Speed Shredder
Doppstadt’s world-leading lineup continues to turn heads with the amazing INVENTHOR 6.2 Slow-Speed Shredder. Cutting-edge in every way, from the drive train concept to the hopper function, this machine has redefined the high-torque, slow-speed shredder concept. Track it into position, fold out the conveyors and take on the most challenging shredding applications with this beast of a machine.
FEATURES:
- State-of-the art Vario Direct drive train concept
- Contaminant resistant
- Unprecedented access to the machine’s interior for ease of maintenance and service
- Enhanced hopper function for optimized feeding
Designed with precision German engineering and built with top quality components, the INVENTHOR 6.2 Slow-Speed Shredder has been engineered to provide the reliability and efficiency needed for a relentless day-to-day operation and long service life.
Specifications
| Transport Length | 300.0 in |
| Transport Width | 107.0 in |
| Transport Height | 133.0 in |
| Working Length | 510.0 in |
| Working Width | 100.0 in |
| Working Height | 144.0 in |
| Overall Weight | 53000.0 lbs |
| Type | 2-speed steel tracks |
| Shaft Length | 86.0 in |
| Shredding Speed | 30 rpm |
| Diameter | 24.0 in |
| Tooth Configuration | 15.0 Teeth |
| Tooth Size | 6.85 in |
| Speed Reverse | 2.0 rpm |
| Loading Height | 125.0 in |
| Loading Width | 132.0 in |
| Width Rear Belt | 48.0 in |
| Speed Rear Belt | 196.0 fpm |
| Discharge Height | 117.0 in |
| Engine Model | MTU 6R1000 |
| Gross Horsepower | 354.0 hp |
| Emissions Tier | Stage V |
| Fuel Tank | 110.0 gal |
| Power Mode | Diesel |
