DEVELON DL200-7 Wheel Loader
The DEVELON DL200-7 wheel loader is engineered for exceptional productivity and maneuverability in construction, agriculture, and material handling applications. Driven by a dependable 142.1 hp Perkins engine, this machine delivers the precise power needed for demanding loading and carrying tasks. With a standard operating weight of 26,559 lbs, it offers operators an ideal balance of robust performance and agility across diverse job sites.
Designed to maximize material movement with every cycle, the DL200-7 features a versatile 2.6 yd³ bucket capacity. Lifting performance is optimized with a straight tipping load of 22,315 lbs, ensuring stability and safety during heavy lifting operations. When paired with haul trucks or hoppers, the loader's impressive dump clearance of 108.0 inches allows for highly efficient material loading and processing
Current Promotions
Current promotions can save you money. We offer promotions that may include Low finance rates, cash back, bonus attachments and more. Check out our current promotional offers to see what may apply to your next equipment purchase.
Specifications
| Operator Protection | ROPS |
| Operating Weight | 26559.0 lbs |
| Overall Length (with Bucket on ground) | 283.8 in |
| Overall Width (over tires) | 100.4 in |
| Overall Height (to top of cab/ROPS) | 130.3 in |
| Wheelbase | 117.3 in |
| Ground Clearance | 17.1 in |
| Turning Radius (Outside Bucket) | 229.7 in |
| Horsepower | 142.1 hp |
| Engine Make & Model | Perkins 1204F |
| Emissions Tier | Tier 4 Final |
| Fuel Tank Capacity | 62.1 gal |
| Bucket Capacity | 2.6 cu yd |
| Breakout Force | 21806.0 lbs |
| Tipping Load (straight) | 22315.0 lbs |
| Tipping Load (full turn) | 19705.0 lbs |
| Height to Hinge Pin | 147.0 in |
| Dump Clearance (@ max height) | 108.0 in |
| Dump Reach (@ max height) | 39.6 in |
| Max Travel Speed | 23.6 mph |
| Auxiliary Standard Flow | 40.9 gpm |
| Tire Size | 20.5R25 L3 |
Specifications and images may vary in accuracy.
