Hydraulics:

Lift cylinder is hard chrome. A permanent magnet pump motor and chrome-plated lift cylinder provides smooth lifting and lowering. Pump unit includes DC motor, solenoid, and gear pump.

Drive:

24-Volt permanent magnet DC drive motor with rare earth neodymium magnets in-creases efficiency and duty cycle.

Frame & Mast:

All steel construction welded rigid steel chassis for added durability. Adjustable forks on pin style carriage. Forks are adjustable from 8” ID to 27.5” OD. Standard fork is 42” long x 3.5” wide x 1.25” thick Non-telescoping mono mast with single lifting chain, adjustable mast rollers. Chrome plated lift cylinder provides smooth lift/lower operation and long life. Three-inch-wide adjustable straddle legs for ease of operation in racked aisles. Four position adjustment allows for preset outrigger dimensions to fit various sized pallets. Straddle leg inside dimension (ID) can be set at 38” to 50” in 4” increments. Fully enclosed wheel guard and flush mounted axles prevent wheel and axle damage during normal use.

Reach out to your local Westerra Equipment dealership to learn more about our full lineup of CLARK pallet jacks!
